| Brand | ASRock |
| Model | EP2C612D8-2T8R |
| Dimensions | 12 x 10 x 3 inches |
| CPU Socket Type | LGA 2011 |
| CPU Type | Supports Intel Xeon processor E5-2600 & v3 series |
| Number of Processor Support | 2 |
| North Bridge | Intel C612 |
| Max Memory Supported | |
| Back I/O Ports | VGA Port:1 x D-Sub, Serial Port:1 (COM1), USB 2.0 Port:2 Type-A (USB2.0), USB 3.2 Gen1 Port:2 Type-A (USB3.2 Gen1), RJ45:2 RJ45 (10GbE), Dedicate LAN:1 dedicated IPMI |
| ECC Supported | Yes |
| PCI Express 3．0 x16 | 3 |
| SATA | 10 x SATA 6.0Gb/s |
| Additional RAID Controller | LSI3008: 8 x SAS3 12Gb/s (miniSAS HD connector) |
| Onboard Video Chipset | Aspeed AST2400 |
| LAN Chipset | 1 x Intel X540 (Support 2 x10GBase-T) |
| LAN Speed | 10G /1G /100Mb/s |
| COM | 1 |
| Video Ports | D-Sub |
| USB ．1/2．0 | 2 x USB 2.0 |
| USB 3．0 | 2 x USB 3.0 |
| Features | 8 x 288-pin DDR4 DIMM slots (Support NVDIMM)2 x RJ45 Gigabit Ethernet LAN ports1 x RJ45 Dedicated IPMI LAN portApplication / Mission critical /and database or VM or HadoopServer with SSD acceleration.Compact Storage Server |
| Form Factor | SSI ATX |
